Product overview
[lbs]
Article #
Dokadek panel 4'-0"x8'-0" ( 110.0 lbs | 586501000 )
Dokadek panel 2'-8"x8'-0" ( 88.4 lbs | 586502000 )
Dokadek-Element
|
Galvanized Painted yellow |
|
Doka floor prop Eurex 30 top 250 ( 28.2 lbs | 586092400 )
Length: 4'-10" - 8'-2" (148 - 250 cm)
Doka floor prop Eurex 30 top 300 ( 36.2 lbs | 586093400 )
Length: 5'-8" - 9'-10" (173 - 300 cm)
Doka floor prop Eurex 30 top 350 ( 45.6 lbs | 586094400 )
Length: 6'-6" - 11'-6" (198 - 350 cm)
Doka floor prop Eurex 30 top 400 ( 54.2 lbs | 586095400 )
Length: 7'-4" - 13'-1" (223 - 400 cm)
Doka floor prop Eurex 30 top 450 ( 64.2 lbs | 586119400 )
Length: 8'-2" - 14'-9" (248 - 450 cm)
Doka-Deckenstütze Eurex 30 top
|
Galvanized |
|
Doka floor prop Eurex 20 top 550 ( 71.2 lbs | 586090400 )
Doka-Deckenstütze Eurex 20 top 550
|
Galvanized Length: 9'-9" - 18'-1" (298 - 550 cm) |
|
Removable folding tripod top ( 26.5 lbs | 586155500 )
Stützbein top
|
Galvanized Height: 2'-7" (80 cm) Delivery condition: folded closed |
|
Dokadek wall clamp ( 9.9 lbs | 183063000 )
Dokadek-Wandhalter
|
Dark brown Length: 4'-6" (138 cm) |
|
Dokadek support head ( 5.3 lbs | 586506000 )
Dokadek-Auflagerkopf
|
Galvanized Height: 1'-1" (33 cm) |
|
Dokadek corner head ( 12.3 lbs | 586539000 )
Dokadek-Eckkopf
|
Galvanized Height: 1'-9" (54 cm) |
|
Dokadek wall head ( 9.5 lbs | 586536000 )
Dokadek-Wandkopf
|
Galvanized Height: 1'-10" (56 cm) |
|
Dokadek edge head 18mm ( 8.8 lbs | 586544000 )
Dokadek-Randkopf 18mm
|
Galvanized Height: 1'-2" (36 cm) |
|
Dokadek cross head ( 5.7 lbs | 586543000 )
Dokadek-Kreuzkopf
|
Galvanized Height: 1'-1" (32 cm) |
|
Spring locked connecting pin 16mm ( 0.55 lbs | 582528000 )
Federbolzen 16mm
|
Galvanized Length: 6" (15 cm) |
|
Dokadek infill beam 8'-0" 3/4" ( 37.3 lbs | 586509000 )
Dokadek infill beam 4'-0" 3/4" ( 19.2 lbs | 586510000 )
Dokadek infill beam 2'-8" 3/4" ( 13.2 lbs | 586511000 )
Dokadek-Ausgleichsträger
|
Galvanized |
|
Dokadek suspension clamp H20 ( 3.5 lbs | 586518000 )
Dokadek-Einhängebügel H20
|
Galvanized Width: 6" (15 cm) Height: 1'-2" (35 cm) |
|
Dokadek timber beam seat H20 ( 12.8 lbs | 586550000 )
Dokadek-Trägeraufnahme H20
|
Galvanized Height: 1'-2" (35 cm) |
|
Dokadek railing shoe short ( 9.5 lbs | 586519000 )
Dokadek-Stirngeländerschuh
|
Galvanized Length: 9" (23 cm) Height: 1'-10" (56 cm) |
|
Dokadek railing shoe short 1.20m ( 6.6 lbs | 586598000 )
Dokadek-Stirngeländerschuh 1,20m
|
Galvanized Length: 9" (23 cm) Height: 11" (27 cm) |
|
Dokadek railing shoe long ( 22.3 lbs | 586520000 )
Dokadek-Längsgeländerschuh
|
Galvanized Length: 4'-1" (125 cm) Height: 2'-2" (66 cm) |
|
Dokadek railing shoe long 1.20m ( 12.6 lbs | 586560000 )
Dokadek-Längsgeländerschuh 1,20m
|
Galvanized Length: 1'-7" (47 cm) Height: 1'-3" (37 cm) |
|
Lashing strap 5.00m ( 6.2 lbs | 586018000 )
Zurrgurt 5,00m
|
Yellow |
|
Doka express anchor 16x125mm ( 0.68 lbs | 588631000 )
Doka-Expressanker 16x125mm
|
Galvanized Length: 7" (18 cm) Follow fitting instructions! |
|
Doka coil 16mm ( 0.02 lbs | 588633000 )
Doka-Coil 16mm
|
Galvanized Diameter: 5/8" (1,6 cm) |
|
Scaffold tube 48.3mm 0.50m ( 3.7 lbs | 682026000 )
Gerüstrohr 48,3mm 0,50m
|
Galvanized |
|
Bracing frame Eurex 4'-0" ( 35.3 lbs | 586557000 )
Bracing frame Eurex 2'-8" ( 32.0 lbs | 586558000 )
Aufstellrahmen
|
Galvanized Height: 3'-8" (111 cm) |
|
Diagonal cross 9.175 ( 13.4 lbs | 582334000 )
Diagonalkreuz 9.175
|
Galvanized Delivery condition: folded closed |
|
Diagonal cross 18.200 ( 17.2 lbs | 582624000 )
Diagonalkreuz 18.200
|
Galvanized Delivery condition: folded closed |
|
Bracing clamp B ( 3.1 lbs | 586195000 )
Verschwertungsklammer B
|
Painted blue Length: 1'-2" (36 cm) |
|
Brace stirrup 8 ( 6.0 lbs | 582751000 )
Spannbügel 8
|
Galvanized Width: 7 1/2" (19 cm) Height: 1'-6" (46 cm) Width-across: 30 mm |
|
Safety plate for brace stirrup 8 ( 0.11 lbs | 582753000 )
Sicherungsblech für Spannbügel 8
|
red Length: 9" (23 cm) |
|
Dokadek plumbing strut connector ( 9.0 lbs | 586537000 )
Dokadek-Justierstützenanschluss
|
Galvanized Length: 11" (28,5 cm) Width: 10" (26 cm) Height: 6 1/2" (16,6 cm) |
|
Plumbing strut 340 IB ( 36.8 lbs | 588696000 )
Justierstütze 340 IB
|
Galvanized Length: 6'-3" - 11'-3" (190,8 - 341,8 cm) |
|
Plumbing strut 540 IB ( 67.7 lbs | 588697000 )
Justierstütze 540 IB
|
Galvanized Length: 10'-2" - 18' (310,5 - 549,2 cm) |
|
Dokadek assembling tool B ( 6.8 lbs | 586540000 )
Dokadek-Montagestange B
|
Aluminum Length: 7'-1" - 12'-8" (215 - 387 cm) |
|
Dokadek assembling tool extension 2.00m ( 3.3 lbs | 586538000 )
Dokadek-Montagestangenverlängerung 2,00m
|
Aluminum |
|
Dokadek suspension tool ( 6.8 lbs | 586562000 )
Dokadek-Einhängestange
|
Aluminum Head part yellow Length: 7'-1" - 12'-8" (215 - 386 cm) |
|
Dokadek stripping tool ( 11.0 lbs | 586541000 )
Dokadek-Ausschalwerkzeug
|
Powder-coated yellow Length: 6'-11" (212 cm) |
|
Dokadek stripping tool extension 1.50m ( 6.8 lbs | 586559000 )
Dokadek-Ausschalwerkzeugverlängerung 1,50m
|
Powder-coated yellow |
|
DekDrive ( 128.0 lbs | 586526000 )
DekDrive
|
Galvanized Length: 4'-9" (145 cm) Width: 2'-11" (88 cm) Height: 3'-7" (108 cm) Delivery condition: folded closed |
|
DekLift 4.50m ( 811.0 lbs | 586553000 )
DekLift 4,50m
|
Galvanized Follow the directions in the "Operating Instructions"! |
|
Platform stairway 0.97m ( 51.8 lbs | 586555000 )
Podesttreppe 0,97m
|
Aluminum Width: 4' (121 cm) Pay attention to the national, technical safety regulations! |
|
Wheel-around scaffold DF ( 97.0 lbs | 586157000 )
Mobilgerüst DF
|
Aluminum Length: 6'-1" (185 cm) Width: 2'-7" (80 cm) Height: 8'-4" (255 cm) Delivery condition: folded closed |
|
Wheel-around scaffold DF accessory set ( 29.3 lbs | 586164000 )
Zubehörset Mobilgerüst DF
|
Aluminum Timber parts varnished yellow Length: 6'-2" (189 cm) |
|
Multi-trip packaging
Dokadek panel pallet 4'-0"x8'-0" ( 165.0 lbs | 586523000 )
Dokadek-Elementpalette 1,22x2,44m
|
Galvanized Height: 10" (26 cm) |
|
Dokadek panel pallet 2'-8"x8'-0" ( 146.0 lbs | 586524000 )
Dokadek-Elementpalette 0,81x2,44m
|
Galvanized Height: 10" (26 cm) |
|
Attachable wheelset ( 60.2 lbs | 586525000 )
Aufsteck-Radsatz
|
Galvanized |
|
Dokadek infill beam pallet ( 137.0 lbs | 586528000 )
Dokadek-Ausgleichsträgerpalette
|
Galvanized Length: 3'-11" (119 cm) Width: 2'-7" (79 cm) Height: 2'-8" (81 cm) |
|
Doka multi-trip transport box 1.20x0.80m ( 154.0 lbs | 583011000 )
Doka-Mehrwegcontainer 1,20x0,80m
|
Galvanized Height: 2'-7" (78 cm) |
|
Multi-trip transport box partition 0.80m ( 8.2 lbs | 583018000 )
Multi-trip transport box partition 1.20m ( 12.1 lbs | 583017000 )
Mehrwegcontainer Unterteilung
|
Steel parts galvanized Timber parts varnished yellow |
|
Doka accessory box ( 235.0 lbs | 583010000 )
Doka-Kleinteilebox
|
Timber parts varnished yellow Steel parts galvanized Length: 5'-1" (154 cm) Width: 2'-9" (83 cm) Height: 2'-6" (77 cm) Special order only! |
|
Doka skeleton transport box 1.70x0.80m ( 192.0 lbs | 583012000 )
Doka-Gitterbox 1,70x0,80m
|
Galvanized Height: 3'-8" (113 cm) |
|
Doka stacking pallet 1.55x0.85m ( 90.4 lbs | 586151000 )
Doka-Stapelpalette 1,55x0,85m
|
Galvanized Height: 2'-6" (77 cm) |
|
Doka stacking pallet 1.20x0.80m ( 83.8 lbs | 583016000 )
Doka-Stapelpalette 1,20x0,80m
|
Galvanized Height: 2'-6" (77 cm) |
|
Bolt-on castor set B ( 74.1 lbs | 586168000 )
Anklemm-Radsatz B
|
Painted blue |
|
