Super Climber SCP
The next generation in self-climbing formwork and working platform technology for highrise cores
Fast assembly and cycling
to increase jobsite production
Optimized concept for fast forming times
- A single stroke cylinder raises all interior and exterior core formwork, all working level platforms and the markets largest concrete placing boom at the push of a button.
- All Formwork, working platforms and concrete placing boom for an entire level can be raised completely independent of the crane.
- Fast forming – when used in combination with the Doka stripping corner, no breaking or re-connecting gangs is required on the inside core wall formwork.
- Fast forming – stripping space required from poured wall can be as little as 1 inch and still climb smoothly.
Maximized efficiencies
to reduce labor costs
A cost-effective solution is ensured by
- Modular formwork and climbing system allows for maximum preassembly to reduce on site labor cost and increase efficiencies.
- Fast climbing – all climbing is reduced to a single activity, no rails to climb ahead or manual placement of shoes required.
- Anchor requirements are comparably reduced saving labor and material costs.
- Hydraulic cylinders are self guiding and self leveling therefore your core will always remain plumb. No need for special water or laser levels.
- Up to 10 climbing brackets can be lifted at one time together from one hydraulic pump
Flexible forming solution
to meet jobsite requirements
Adaptable design to achieve results
- Cores with forming heights of up to 20 feet can be poured with the slabs or climbed ahead of slab pours
- All climbing operations are done from below the core formwork
- Modular standard components of the system minimize time and labor for initial setup.
- Designed with all standard Doka parts and can be used in conjunction with all other Doka climbing systems.
- High load capacity of gantry platform provides a large site storage area for material storage on top of core.
Built in Safety
for the entire jobsite
All operations can be carried out safely and quickly
- Working points are reduced to a few simple steps
- Solutions are available to protect workers from all climate conditions.
- Working operations can be designed independent of any weather influences.
- All formwork is suspended from a high capacity superstructure reducing jobsite crane pick requirements.
