Folding platform K

The pre-assembled scaffold platform for concrete construction sites

Doka folding platforms K are pre-assembled, work-ready scaffold platforms with standardised system components for all usage situations.


Tested safety
for reliable pro­tection

Put the advantages of this EN 12811-1 and DIN 4420 certified Service and Working Scaffold to work for you

  • reduced costs, due to fast, safe working
  • high load-bearing capacity (max. 600 kg/m²) means that wall formworks up to 5.50 m high can be stood on the platforms
  • unobstructed, flat platform deck made possible by the retractable crane-hoisting points
  • with practical add-on components for every usage situation

Rapid working
thanks to easy handling

Reduced labour and crane times, thanks to

  • pre-assembled units
  • planning where to put the suspension points is easy, thanks to the system's logical concept
  • ready for use straight away, after a very few quick and easy actions

can be used for all types of safety task

Depending on your needs, you can use the pre-assembled scaffold platforms as

  • working platforms
  • pro­tection platforms
  • sloping-rooftop fall barriers
  • protective canopies

Highly cost-efficient
saving you time and money

Achieves cost-optimisation by

  • being easy to use
  • having a long lifespan
  • not taking up much storage and transport space



  • system consists of two straight platforms (3.00 m and 4.50 m long) and a corner solution
  • two different suspension methods and a wide range of accessories for adapting to site requirements
  • high load-bearing capacity of up to 600 kg/m² (= Scaffold Category 6)
  • platform level can be raised / lowered by either 0.50 m or 1.00 m at a time
  • long service life thanks to its sturdy design, varnished floor planking and galvanised steel construction
  • planking protected by steel section on the narrowside

The fold-away Folding platform K corner solution makes for safe, time-saving corner transitions without any trip hazards and loose decking boards.

Adding Handrail extensions K and safety netting turns the platform into a dependable sloping-rooftop fall barrier.

Types of suspension point

The standard suspension point is prepared by screwing a suspension cone into an embedded positioning-point.

To use the Folding platform K with loop-type suspension points, simply retrofit the platform with the Bow head K-ES.

A suspension plate can be used to retrofit a dependable suspension point to the concrete floor-slab whenever needed.

The Fair-faced concrete positioning cone 15.0 5cm can be used to ensure that the form-tie points and suspension points produce a uniform hole-pattern.


The Folding platforms K are pre-assembled and can be transported and stored folded closed. This saves space and keeps them safe from overturning and slipping. This high packing density translates into low shipping volume and excellent utilisation of the loading area of the truck.
