Back to overview

3-ply sheets

for vibrant concrete finishes

Doka 3-ply sheets provide the basis for many Doka formwork systems and have a wide range of uses. Doka has the right solution for all requirement, covering anything from standard applications to rentable panels.

DownloadsVideos

Formwork sheet 3-S plus

The 3-ply sheet for Doka tableforms

High numbers of repeat uses and even, uniform concrete finishes thanks to the high-grade PU sealing-layer, which ensures high dimensional stability and minimises cracking.

Formwork sheet 3S basic

Formwork sheet 3S basic

Multiple use and prevention of positive imprints through closed surface on both sides coated with high-quality melamine resin. Lower costs for finishing work based on high dimensional and angle accuracy.

Formwork sheet 3-SO

High-performing quality sheet for special requirements and many applications

First-rate concrete results through choice timber and superior surface treatment Highly durable through specially aligned face ply and high dimensional stability

Texture sheet 3-SO

The sheet for board-type surface structures

Visually appealing concrete faces with a board-type surface structure and ribbed finish, achieved by the brushed surface with recessed grooves (V-groove centres: 125 mm, V-groove width: 6.5 mm. V-groove depth: 3 mm) and high-quality varnish sealant.

References

Formwork sheet 3-S plus

Formwork sheet 3-S plus

  • Type: 3-ply formwork sheet made of spruce
  • Surface: urea-melamine resin adhesive
  • high degree of format accuracy
  • Surface sealing: single-side varnish sealant layer sanded with corundum particles
  • Glue-bonding: boilproof and weathering-resistant
  • Edge: Doka yellow impregnating emulsion
Formwork sheet 3-SO

Formwork sheet 3-SO

Quality you can rely on, time after time

  • Type: 3-ply formwork sheets made of spruce, crosswise glue-bonded, with / without edge strip
  • Surface: high-quality urea-melamine resin glue
  • choice quality timber
  • high degree of format accuracy
Formwork sheet 3S basic

Formwork sheet 3S basic

The low-cost 3-ply sheet with a long lifespan

  • Type: 3-ply formwork sheet made of spruce, crosswise glue-bonded, with edge strip
  • Surface: urea-melamine resin adhesive
  • high degree of format accuracy
Texture sheet 3-SO

Texture sheet 3-SO

  • Type: 3-ply concrete formwork sheet for board-type surface textures, rear side can be used as a standard formwork sheet
  • Surface: Wood texture with special resin coating
  • Glue-bonding: boilproof and weathering-resistant
