Kömürhan Bridge

Malatya-Elazig, Turkey

The Kömürhan Bridge is under construction some 700 kilo-metres east of the Turkish capital Ankara and 400 kilometres north of the Syrian border. It is 660 metres long and consists of a cable-stayed bridge with a single pylon with a height of 165 metres.

Challenge:
The pylon, and especially its unusual form, represent-ed the main challenge in the search for a practical formwork solution.

Solution:
Automatic climbing formwork SKE50 was used for the upper single-core pillar of the pylon, while for the lower half a specially adapted double set with customised solutions at the intersections was used to guarantee top quality and safety.

Back to overview
Reference Title
Reference Title
Reference Title

Project data

Year of completion
2020
Project duration
2017 - 2020
Country
Turkey
City
Malatya-Elazığ
Contractors
Doğuş and Gülsan Holding

Building data

Length
660 m
Main Span
360 m
Height of pylon
165 m
Concrete
160,000 m³
Reinforcement
6,000 tons
