Opaži

Doka nudi opažne rešitve za vsa področja gradnje, tako za stanovanjske komplekse, gradnjo prometnih poti, izgradnjo energetske infrastrukture ali gradnjo najvišjih objektov na svetu. Za vsak gradbeni projekt in vsako zahtevo so vam na voljo ustrezni opažni sistemi in komponente. Modulna zgradba omogoča idealno usklajevanje sistemov in komponent.

opaži

Choosing the suitable formwork system for your project's needs

For choosing the proper formwork among others the following project criteria needs to be considered:

  • Structure of the building
  • Concrete surface
  • Formwork height
  • Load and slab thickness
  • Fresh-concrete pressure
  • Building site conditions
  • Execution time
  • Number of cranes and crane capacity
  • Number of workers available
  • Safety
  • Number of re-uses
  • Number of form tie patterns
  • etc.

Further on relevant project criteria need to be matched with the features of formwork systems in focus. This way a suitable solution could be defined. An example with chosen concrete forms could look like this:

RequirementFramaxFF20Top 50Special formwork
Framed FormworkTimber-beam Formwork
Frame impressionsyesnonono
Join patternin gridin gridfreely selectablefreely selectable
Form tie patternin gridin gridfreely selectablefreely selectable
Formwork sheetingPlywood, film-coatedThree-ply sheetfreely selectablefreely selectable
Geometryfixed widths / heightsfixed widths / heightsadaptableadaptable
Concrete pressureMax. 80 kN / m²Max. 50 kN / m²adaptableadaptable
