10k Shoring System

The proven load-bearing tower made of steel

Doka’s 10k/leg shoring system is the proven method for shoring slabs at a wide range of heights and is especially effective for heights over 18 ft. Combining European technology with American methodology, the 10k system works well in conjunction with our Dokaflex and Dokamatic table systems.

Downloads

High leg load capacity
Combined with flexible range of use

Benefit from the advantages of various sizes

  • A wide range of loading capacity is available up to 17,300 lbs/leg
  • Frames are available in 2’ or 4’ width and 3’, 4’, 5’, and 6’ height
  • Cross braces are available in 3’, 4’, 5’, 6’, 7’, 8’, and 10’ widths allowing the frames to be spaced from 3 ft. to 10 ft. apart

Huge Flexibility
In on-site use

Make work easier for your crew because

  • Doka H20 beams, aluminum or steel junior beams are used for stringers
  • Doka H20 timber beams or aluminum beams are used for joists
  • Doka’s engineering department will provide detailed layout drawings and calculations if required
  • Doka maintains an inventory at each location which is available for immediate delivery
